100 Pieces Wago 221-413 Connection Terminal 3 Wires with Lever 0,2-4 qmm Small Design, Transparent

$81.99

  • Comfortable conductor connection from 0.2 to 4 mm².
  • Installation of single, fine and multi-strand conductors.
  • Lever on, ladder in, close lever.
  • For all types of conductors.
  • 32 A/450 V.

Out of stock

  • International Express shipping available
  • 30 day easy returns
Guaranteed Safe Checkout

Description

Electrical data:
Rated data according to IEC/EN 60664-1. Rated voltage (II/2): 450 V. Rated surge voltage (II/2): 4 kV. Rated current: 32 A.
Connection data:
Connection technology: Cage clamp. Actuation type: lever. Connectable conductor materials: copper. Nominal cross section: 4 mm². Solid conductor: 0.2 – 4 mm²/24 – 12 AWG. Multi-strand conductor: 0.2 – 4 mm²/24 – 12AWG. Fine-stranded conductor: 0.14 – 4 mm²/24 – 12AWG. Stripping length: 11 mm / 0.43 inches. Total number of clamping points: 3. Total number of potentials: 1. Wiring type: side wiring. Conductor cross-sections single-wire: 0.2 mm². Geometric data:
Width: 18.7 mm / 0.736 inches. Height: 8.3 mm / 0.327 inches. Depth: 18.6 mm/0.732 inch.
Material data:
Colour: transparent. Flammability class according to UL 94: V2. Fire load: 0 MJ. Weight: 2527g
Environmental conditions:
Ambient temperature (operation): 85°C. Continuous operating temperature: 105 °C. T-mark according to EN 60998: T85.

Additional information

Weight 0.3 kg
brand

WAGO

dimensions

11.4 x 8.6 x 8.6 cm; 310 Grams
