BACOENG 1" DN25 Brass BSP 2 Port Motorized Ball Valve (AC110-230V CR202 2 Wires Normally Closed Electric Ball Valve): Valve Body: 1" DN25 Brass BSP 2 Way; Normally Closed; Orifice Size: 24mm, Full Bore. Actuator: AC110-230V; Wiring type: CR202 Two wires control (Spring Return When Power Off); Metal Gears Inside; With Indicator.
Key features
- Valve Body: 1" DN25 Brass BSP 2 Way; Normally Closed; Orifice Size: 24mm, Full Bore
- Actuator: AC110-230V; Wiring type: CR202 Two wires control (Spring Return When Power Off); Metal Gears Inside; With Indicator
- Protection Class: IP67; Maximum Working Pressure: 10 bar; Open/close Time: 3-5 sec; Max Torque: 2 N·m (A20 Series)
- Material: Brass
- Size: 1" Brass
Product specifics
- Brand: BACOENG
- Category: Intake Valves
- Size: 1" Brass
- Material: Brass
- Model: P0329
- Part number: P0329
