Description
Features:
*Observe the signal level LED, monitor the signal level status
*Provide truly professional +48V phantom power for condenser microphones
*Insertion point for external effect processing
*Mixer input channel specifications 8/12 channels
*AUX sends all can be switched to pre-fader or post-fader
*FX send
Technical specifications:
Frequency response: microphone/line input to any output end, 20Hz-20KHz ±0.5dB
Total harmonic distortion and noise: -30dBu input to the mixing, microphone gain 30dB, <0.007%
Equivalent input noise of microphone input: 22Hz-22KHz unweighted, -128dBu
(The internal resistance of the source is 150Ω).
Bus noise: 20Hz-20KHz broadband line input, terminal load is 150Ω, RMS (effective value) measurement.
Mixing: the fader is below, the mixing level, 96dB; fader position (marked +10), >96dB;
Auxiliary sending port, >86dB.
Output level: microphone/line input level is +17dBu; line input level is +30dBu; stereo input level is +30dBu; mixing output level is +20dBu; headphone output level is 300mw/200Ω.
EQ (mono input): HF (high frequency): 12KHz±15dB; MF (intermediate frequency): 140Hz-3KHz, ±15dB, Q=15; LF (low frequency); 80Hz, ±15dB.
Output level meter: L and R mixing output level meter is a 12-segment LED indicator.
Working conditions: temperature range: -10℃～+30℃; relative humidity: 0%～80%.
Package list:
1 * Mixing Console
1 * Power Adapter
1 * User Manual (English)
Hardware Interface:- Bluetooth
Power Source:- Usb
Item Weight:- 5.55 kg
Date First Available:- 15 Sept. 2020
Package Dimensions:- 51.7 x 45.8 x 18.9 cm; 5.55 Kilograms
Manufacturer:- bomaite
Brand:- bomaite
Number of channels:- 10
Product dimensions:- 40.5D x 39.5W x 13.5H centimetres
Connectivity technology:- Bluetooth, USB
Power source:- Usb
