Description
This OSD is suitable for advanced users with (good) electronics skills. Not for beginners! If you connect or modify something incorrectly, you can shoot your entire aircraft electronics in the worst case. Please disassemble the MinimOSD before using it. If the OSD sporadically shows no more information, this is very likely due to your voltage converter. As soon as there is a voltage fluctuation, the processor hangs on the OSD and the board needs a reset. This often happens when switched on afterwards, activating:
Best donate a common voltage converter to the OSD board with your flight controller. Firmware: As this is an open source OSD, you have the option to use different firmware to match your flight controller. APM or controller with MAVLink protocol: https://codele/p/arducam-osd/downloads/list Multiwii or controller with Multiwii protocol: https://codele/p/rush-osd-development/ NAZA M V1/V2/Lite or controllers that correspond to: https://codele/p/minnazaosd/ Openpilot compatible controllers: https://codele/p/minoposd/ The best way to read is through an OSD wiki to match your flight controller.
Specs:
