Description
These DB9 Female Solderless Connectors are used to terminate the connection type of a cable and facilitate commissioning equipment of project.
They can easily be connected to a custom length cable as well as create a custom pinout, creating a permanent and durable connection for all applications.
These connectors are made with high-quality materials to ensure durability and a long life.
Technical Specifications:
Name: Thin DB9 solderless module
Plug type: female
Accessories: housing, screw, card line buckle
Connector material: pure copper plated joint
Contact Material: Copper
Housing material: Zinc alloy metal shell
Shell type: Screw lock
Pin Pitch: 3.81mm/0.15in
Cable Specification: 28-16 AWG/0.15-1.5mm2
Torque: 0.2Nm (1.7Lb-In.)
Opening size (cable port): 10.5mm/0.41″
Thickness: 16mm/0.63″
Application: tax control machine, digital camera, PLC, PDA, MODEM, set-top box, barcode machine, industrial instrumentation, etc.
Size: 49 mm×35 mm×16 mm/ 1.93″×1.38″×0.63″
Package includes:
1 x DB9 Male Solderless Connectors
2x Lock screws
2x Long bolts
1x 5mm tail pipe
1x 6mm tail pipe
1x 7.5mm tail pipe
1x 8.5mm tail pipe
