Description
e: Doorbell
Main control: XR872
Memory: 32Mb Flash
Sensor: 30W GC0328 CMOS sensor
Lens: 100° wide-angle lens;
Sensor performance: support automatic white balance, automatic gain control, automatic backlight compensation
Signal-to-noise ratio: ≥41dB
Minimum illumination: 0.8lux/F1.4 (color mode), 0.3lux/F1.4 (black and white mode);
Night vision: 2 850nmΦ28mil high-power infrared lights;
Night vision distance: 1 meter is the best, the longest distance is 3 meters
Video format: JPG;
Video size/frame rate: 480P/7fps;
Recording method: 1. Press the button to start recording;
Cloud storage map: 5 seconds (5 pictures);
Battery type/capacity: polymer 803035/800MAH;
Battery discharge time: polymer battery standby for 1 year;
Network protocol: TCP/IP/HTTP/TCP/UDP/DHCP/DNS/DDNS/NTP/RTP/P2P;
WIFI connection: 2.4GHz wifi, support (802.11 b/g/n);
Ding Dong: Support 433MHZ Ding Dong;
Storage: Support cloud storage function (no TF card function), 3 days free circulation “cloud storage”;
Working voltage: polymer 803035/3.7V;
Working current: 219mA working current, 10mA deep sleep current, 280mA open infrared working current;
USB charging voltage: DC 5V / 1.5A;
Storage temperature (℃): (0℃~50℃);
Working temperature (℃): -10～50℃, working humidity <95%;
Activation method: 1. The doorbell button is activated;
APP access rules: 1 main account + 8 shared accounts = 9 users can connect to the doorbell, only 3 users can preview the screen at the same time, and only one user can talk to the doorbell at a time"
Packing list:
1 x doorbell
1 x Ding Dong machine
1 x package accessories
1 x instructions
1 x packing box
