Description
Features:High resolution, can generate sine/triangle/square waveformsuency range: 1Hz-1MHzstable frequency and amplitudeuency adjustment features coarse tuning and fine tuning power supply range, use 9-12V external power or 9V battery(NOT Included) are through hole components, easy for installationifications:Voltage Supply: 9-12V DC InputWaveforms: Square, Sine & TriangleImpedance: 600 Ohm + 10%Frequency: 1Hz-1MHzSINE WAVEAmplitude: 0-3V at 9V DC InputDistortion: Less than 1% (at 1KHz)Flatness: +0.05dB 1Hz – 100kHzSQUARE WAVEAmplitude: 8V (no load) at 9V DC InputRise Time: Less than 50ns (at 1KHz)Fall Time: Less than 30ns (at 1KHz)Symmetry: Less than 5% (at 1KHz)TRIANGLE WAVEAmplitude: 0-3V at 9V DC InputLinearity: Less than 1% (up to 100KHz) 10mAPackage Size: Approx. 12 * 8 * 2cm / 4.72 * 3.15 * 0.8inPackage Weight: 69g / 2.46ozPackage List:1 * Signal Generator DIY Kit1 * User Manual(English)
