Ganter Normelemente GN 817-8-12-BK Indexing Plunger, Black, Pin Diameter: 8mm Detent Travel: 12mm: Form BK: without locking lock, with lock nut. Locking path l1: 12 mm; thread length l2: 58 mm; bolt diameter d1: 8 mm; thread d2: M16 x 1.5; hex length l3: 26 mm.
Key features
- Form BK: without locking lock, with lock nut
- Locking path l1: 12 mm; thread length l2: 58 mm; bolt diameter d1: 8 mm; thread d2: M16 x 1.5; hex length l3: 26 mm
- Spring pressure in N: 8.5 (beginning) – 28 (beginning) end) RPA. 20232023design: burnished steel; locking pin: hardened
- Material: Alloy Steel
- Colour: Black
Product specifics
- Brand: Ganter Normelemente
- Category: Latches & Bolts
- Size: Pin diameter: 8mm; detent travel: 12mm
- Colour: Black
- Material: Alloy Steel
- Model: GN 817-8-12-BK
- Part number: GN 817-8-12-BK
