RATTMMOTOR CNC Linear Guide Rail 200 mm Travel Length Linear Actuator Slide Stage Linear Motion Table SFU1605 Ballscrew with NEMA23 Stepper Motor: Basic parameters-speed 0-200 mm/s, effective stroke 200 mm, repeat the positioning accuracy of ± 0.03 mm； pitch 5 mm (the incline spindle moves 5 mm in one rotation). 1605 Ball Screw- Drive Type: Cbx1605 Ball Screw. Effective Travel Length: 200Mm. Screw Precision Grade: C7. Screw Pitch: 5Mm. Flange Nut Screw Rod With Precision Up To 0.03Mm.
Key features
- Basic parameters-speed 0-200 mm/s, effective stroke 200 mm, repeat the positioning accuracy of ± 0.03 mm； pitch 5 mm (the incline spindle moves 5 mm in one rotation)
- 1605 Ball Screw- Drive Type: Cbx1605 Ball Screw. Effective Travel Length: 200Mm. Screw Precision Grade: C7. Screw Pitch: 5Mm. Flange Nut Screw Rod With Precision Up To 0.03Mm
- Suitable for linear motion guides use
- Material: Aluminium
- Size: Effective stroke=200mm
Product specifics
- Brand: RATTMMOTOR
- Category: Linear Motion Guides
- Size: Effective stroke=200mm
- Material: Aluminium
- Model: RTM-CBX1605
- Part number: RTM-CBX1605
