Features:
– Multiple functions: including voice function, app control, timer and sharing for multiple users.
– Calibration in the app is required before use.
– You can place the remote control anywhere that is convenient for you.
– The strong radio frequency broadcast works through walls and doors.
– The receiver fits into standard cavity wall boxes.
– Wireless roller shutter switch kit for electric shutters, curtains, blinds and awnings.
Three control ways:
1. Add one RF remote control per switch.
2. After connection, the roller shutter switch is controlled by the graffiti app.
3. Install a conventional switch to turn the device on or off.
Specifications:
Nominal voltage: AC (AC voltage) 100 V – 240 V.
Operating frequency: 50/60Hz.
Frequency: 433 MHz.
Standby power consumption: 0.2 W.
Load capacity: 16 A.
Range: 30-100 m.
Working temperature: -20~55℃.
Receiver size: 45 x 50 x 23 mm
Remote control size: 71 x 71 x 51 mm.
Package includes:
1 x RF receiver.
1 x RF remote control.
(Built-in dry battery).
